ENGINE WELDER 系列 HW220-EW 汽油发电电焊机 | GT1300发动机 5.6kW 230A 无刷诱导子技术 野外焊接优选/ENGINE WELDER Series HW220-EW Gasoline Engine Welder | GT1300 Engine 5.6kW 230A Brushless Inducer Technology – Ideal for Field Welding

【产品概述】
ENGINE WELDER 系列 HW220-EW 是一款汽油驱动发电电焊机，由 北京安捷伟达科技有限公司 提供。本产品采用 DENOH/GT1300 单缸油浴式发动机，结合无刷诱导子发电技术，为野外无电环境提供稳定、高效的焊接电源与辅助电力。适用于油气管道、铁路建设、工程机械维修、抢险救灾等场景。

【核心优势】

• 高效耐用发动机：搭载 DENOH/GT1300 四冲程单缸油浴式发动机（391cc，13HP），油浴式设计有效降低磨损与故障率，抗风沙能力强，尤其适合野外恶劣工况，使用寿命更长。

• 无刷诱导子发电技术：发电效率高，提供效果更优良的焊接电源，减少维护需求。

• 高低档电流快速切换：配备高低档电流选择开关，不需停机与插拔快速插头，即可在作业中快速调整电流，提升工作效率。

• 机油报警保护：内置机油报警系统，既节能又减少发动机磨损，防止非正常情况启动，确保发动机安全并延长使用寿命。

• 焊接性能优异：适用多种焊条，可出色施行纤维素焊条、低氢焊条及氩弧焊的全位置焊接。电弧稳定、飞溅小，手感细腻流畅。

• 辅助电源输出：标准配置3kW直流辅助电源（DC220V），可为角磨机、照明、水泵等多种电动工具提供现场电源。可选配交流逆变器，将直流输出转换为交流电，适用范围更广。

• 坚固耐用设计：防护等级IP21，绝缘等级F，适应户外作业环境。

【主要技术参数】

【适用场景】

• 野外油气管道焊接施工

• 铁路建设与维护

• 工程机械及车辆维修

• 武器装备抢修

• 抢险救援、救灾应急

• 偏远地区无电网施工作业

【启动与操作说明】

1. 启动前检查：检查机油油位（标准1.0L）、燃油油位（油箱容量12L），确保各连接紧固。

2. 手动启动：采用手动拉绳启动（无电瓶），按操作规范启动发动机。

3. 焊接调节：通过高低档电流选择开关，在50-230A范围内快速调节焊接电流，无需停机或插拔插头。

4. 辅助电源使用：将直流辅助电源断路器合上，即可为DC220V电动工具供电。如需交流电，可选配交流逆变器。

5. 停机：关闭发动机，待完全停止后进行检查维护。

【维护与注意事项】

• 定期检查机油油位和质量，及时更换。

• 定期清洁空气滤清器，尤其风沙较大环境需增加清理频次。

• 使用无铅汽油，避免劣质燃油损坏发动机。

• 长期存放时排空燃油，防止化油器堵塞。

• 根据使用频率定期检查火花塞、气门间隙等关键部件。

【定制与服务】
本设备可依据客户需求选配不同品牌发动机、车轮组件及交流逆变器等附件。具体报价请来电咨询：86-010-86468776，手机/微信：13521628344。

【Product Overview】
The ENGINE WELDER Series HW220-EW is a gasoline-driven engine welder provided by Beijing Anjie Weida Technology Co., Ltd. Featuring the DENOH GT1300 single-cylinder oil-bath engine combined with brushless inducer power generation technology, this unit delivers stable, efficient welding power and auxiliary electricity for off-grid field operations. Ideal for oil & gas pipelines, railway construction, engineering machinery repair, and disaster relief.

【Key Advantages】

• Durable & Efficient Engine: Powered by the DENOH/GT1300 4-stroke single-cylinder oil-bath engine (391cc, 13HP). The oil-bath design reduces wear and failure rates, with strong resistance to sand and dust – perfect for harsh field conditions, ensuring extended service life.

• Brushless Inducer Generation Technology: Delivers high generation efficiency and superior welding power quality with reduced maintenance requirements.

• Quick Current Switching: Equipped with high/low current selection switch – adjust welding current on the fly without stopping the engine or unplugging cables, significantly improving work efficiency.

• Oil Alert Protection: Built-in oil alert system saves fuel, reduces engine wear, prevents abnormal starts, and extends engine life.

• Superior Welding Performance: Compatible with a wide range of electrodes – excels at cellulose, low-hydrogen, and TIG welding in all positions. Features stable arc, low spatter, and smooth, precise operation.

• Auxiliary Power Output: Standard 3kW DC auxiliary power supply (DC220V) – powers grinders, lights, pumps, and other tools on-site. Optional AC inverter converts DC to AC for broader application compatibility.

• Rugged Design: IP21 protection rating and Class F insulation, built for outdoor operations.

【Key Specifications】

【Applications】

• Off-grid oil & gas pipeline welding

• Railway construction and maintenance

• Construction machinery and vehicle repair

• Military equipment field repair

• Disaster relief and emergency response

• Remote construction sites without grid power

【Startup & Operation】

1. Pre-start Check: Verify oil level (1.0L standard) and fuel level (12L tank), ensure all connections are secure.

2. Manual Start: Pull-start (no battery required) – follow standard starting procedure.

3. Welding Adjustment: Use the high/low current selector switch to adjust welding current from 50-230A without stopping the engine or unplugging.

4. Auxiliary Power: Close the DC auxiliary power circuit breaker to supply DC220V to power tools. Optional AC inverter available for AC output.

5. Shutdown: Turn off the engine and perform inspection/maintenance after complete stop.

【Maintenance & Precautions】

• Regularly check and change engine oil per maintenance schedule.

• Clean air filter regularly – more frequently in sandy or dusty conditions.

• Use unleaded gasoline only – avoid poor quality fuel that may damage the engine.

• Drain fuel for long-term storage to prevent carburetor clogging.

• Periodically inspect spark plugs, valve clearance, and other key components.

【Customization & Contact】
This unit offers optional engine brands, wheel assemblies, and AC inverter accessories. For pricing and configuration, please contact: 86-010-86468776 (Mobile/WeChat: 13521628344).
